Description Optical: Light Source: 1 LED (warm white), 230W, 3.3A Color Temperature: 3422K (warm white) CRI (Color Rendering Index): High CRI (exact value typically 90 for warm white models, though not always specified) Beam Angle: Varies with interchangeable lens plates: Narrow: ~11° Medium: ~21° Wide: ~37° Field Angle: Varies with lens: Narrow: ~20° Medium: ~39° Wide: ~68° Lumens: Up to 8,644 (depending on lens and configuration) Illuminance (with lens): Narrow: ~17,000 lux @ 5m Medium: ~5,500 lux @ 5m Wide: ~2,000 lux @ 5m PWM Frequency: Adjustable (600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, or 25,000 Hz) for flicker-free operation Dynamic Effects: Dimming: Electronic, 16-bit smooth dimming (0-100%) Dimmer Curves: 4 selectable dimming curves Strobe: Electronic, 0-30 Hz Standalone Color Mixing: No (monochromatic warm white) Construction / Physical: Dimensions: 12.48 x 9.65 x 6.85 in (317 x 245 x 174 mm) Weight: 11.2 lbs (5.1 kg) Housing Material: Aluminum die-cast Finish: Black Accessory Holder/Gel Frame Size: 7.5 in (191 mm) standard PAR accessory compatible IP Rating: IP20 (indoor use only) Connections: Power Input: Neutrik powerCON Power Output: Neutrik powerCON (for linking) Data Connectors: 3-pin and 5-pin XLR (DMX) Cable Length (power): 5 ft (1.5 m) Electrical: Input Voltage: 100-240 VAC, 50/60 Hz (auto-ranging) Power Linking: 6 units @ 120V 11 units @ 230V Power Consumption: 250W, 2.1A @ 120V; 245W, 1.1A @ 230V Control: Control Protocol: DMX, RDM (Remote Device Management) DMX Channels: 1, 2, 3, or 5-channel modes Modes/Personalities: Multiple DMX personalities for simplified or advanced control Thermal: Maximum External Temperature: 104°F (40°C) Cooling: Convection (virtually silent operation) Certifications: CE, MET Additional Features: Interchangeable lens plates (narrow, medium, wide) included Silent operation, ideal for theatrical, broadcast, or studio environments Compatible with standard beam-shaping accessories (top hats, barn doors, etc.) This wash light is designed for versatility and high-quality warm white illumination, making it a popular choice for professional lighting applications where even coverage and quiet performance are critical.
