Allen & Heath GX4816 Audio Expander Features A 5U, 48-input/16-output, 96kHz digital I/O expansion for A&H dLive and SQ mixing consoles Each input features a remote-controllable microphone preamp with individual phantom power LEDs Two DX expansion ports let you hook up 1 DX32 or up to 2 DX168/ DX164-W expanders Connect up to 2 GX4816s to an SQ system, 3 to a dLive C Class system, or 5 to a dLive S Class system Plug-and-play connection via standard Cat 5e cables (EtherCon ports) with automatic IP addressing Tech Specs Type: Portable GX Expander Compatibility: A&H dLive, SQ mixing consoles Channels: 48 x 16 Inputs – Mic Preamps: 48 x XLR Outputs – Main: 16 x XLR Data I/O: 1 x EtherCon (GX), 2 x EtherCon (DX) Rackmountable: 5U Power Source: Standard IEC AC cable Height: 9″ Depth: 10″ Width: 18.9″ Weight: 17.6 lbs.
