EK NF is the ideal nearfield monitor solution for any kind of music production applications. From the carefully selected transducers to the proprietary enhanced waveguides and to the low resonance cabinet design, everything has been tailored to offer the best accuracy over the whole audio spectrum. The perfectly optimized electronics, including high headroom separate Class AB amplifiers for high and low section, high precision crossover networks and separate LIMITER circuits, provide maximum resolution and minimum listening fatigue.Active vented sub-wooferLong-excursion 10” woofer with PP cone featuring very extended responsePrecisely calculated front tuning port for greater low-frequency extensionStereo balanced inputs, outputs and link connectors for MONO and STEREO operationOptimized crossover design with HI-CUT and LO-CUT frequency controlHigh-headroom Class AB 150W amplifier with accurate CLIP LIMITERTECHNICAL SPECIFICATIONSSystem typeVented sub-wooferLow Frequency Device10” woofer with PP coneLF Amplifier Continuous Power150W Class ABProcessingAnalogFrequency Response40 Hz – 150 HzMax SPL110 dBConnectors1/4” JACK, XLR-F (stereo INPUT), XLR-M (stereo OUTPUT), XLR-M (LINK)ControlsLEVEL, HI-CUT & LO-CUT frequency selector, PHASEConstructionVinyl laminated MDF cabinet with MDF frontCabinet ColourBlackPower Supply230 VAC or 120 VAC 50/60 Hz with LINE VOLTAGE selectorDimensions (W x H x D)330 x 365 x 365 mmWeight15.3 kg
